Topcon LS-B4 User Manual

6 SPECIFICATIONS
6-1
6 SPECIFICATIONS
Vertical Sensing Range : 200mm / 7.875 inches
Horizontal Sensing Radius : 360 degrees
ON GRADE Tolerance : (Using Topcon RL-H1Sa laser)
*Tolerance may vary depending on laser detecting distance, rotating laser being used or atmospheric
conditions.
Detectable laser wave length : 633nm~780nm
Laser Detecting Range : 600m / 1960 ft diameter
: (Using Topcon RL-H1Sa laser)
Grade Information Channels : 5 display steps plus out-of-beam
high and low
Modes On-Grade Tolerance
Mode1 ±6mm / 0.02ft
Mode2 ±20mm / 0.06ft
