5 OPTIONAL ACCESSORIES
5-5
5.2.2 RD-2 Installation
On a v
er
tical or hor
izontal surf
ace of a machine, install RD-2 using its optional
mounting hardware as sho
wn below
.
Installation on v
er
tical surface
Installation on horizontal surf
ace
RD/IR-2 adapter
RD/IR-2 adapter
The RD/IR-2 adapter is an optional accessor
