2 PREPARING FOR USE
2-6
2.2 P
ower s
witch ON and OFF
The pow
er can be tur
ned on b
y pressing the PO
WER s
witch.
The Mode 1 indicator will illuminate.
Pressing the PO
WER switch again turns off the power
.
Mode 1 indicator
P
ow
er s
witch
