5.2 RD-2 Remote Display
The RD-2 allows the LS-B4 display to monitored in a convenient location, such as in
the cab of a dozer.
5.2.1
Nomenclature
Power switch
Mode selection
switch
Mode indicator
Display
Connector for LS-B4
Power supply connector
Control key
(For use with expanded control systems. Inactive with the
LS-B4 as described in this booklet.)
