5 OPTIONAL ACCESSORIES
5-3
5.1.2 Using the machine battery to power LS-B4
MODE
POWER
PC-20 (#9060-5087)
When the LS-B4 is connected to the machine's
batter
y
, power automatically supplied to the LS-B4
and the pow
er s
witch is disabled.
Red
Black
Batter
y of
the machine
LS-B4E-1.book
3
ページ
２００１年５月１８日 金曜日 午前１１時５９分
33
35
