2.7 Display Information
The LS-B4 display is a high-intensity colored LED array that provides a visual guide
for positioning the cutting edge of the machine to a predetermined on-grade elevation.
As the LS-B4 is moved through path of the laser beam, the display will provide seven
channels of information as described on the next page.
Display
