1NOMENCLATURE AND FUNCTIONS
1-2
1.2 FUNCTIONS
When this instrument is used with a rotating laser, the display (red, yellow and green
LED's) indicate the direction the cutting edge of the machine should be moved in order
to obtain the preset on-grade position.
This instrument can also be used in conjunction with the Trackerjack (Laser Tracker
package, C model) as the primary rotating laser receiver for any Topcon equipment
automation system (System Five, System Four, Touch Series 5, etc).
LS-B4E-1.book2 ページ ２００１年５月１８日 金曜日 午前１１時５９分
