5 OPTIONAL ACCESSORIES
5-8
5
Press the mode switch on the RD-2 to set the on-grade tolerance.
(Refer to 2.7 Display Information for information.)
6
Move the LS-B4 up and down until the RD-2 display shows ON GRADE.
7
Tighten the clamp knob of the LS-B4 securely.
8
Start to work.
Note:
There are four mode indicators (1~4) on the RD-2 display.
Only two mode indicaters(1~2) are used when the LS-B4 is connected.
