Introduction
Bench Test
1-3
P/N: 1049060-01
Required Tools
• MC Systems Calibration Kit, P/N 1031278-01
• Metric wrench set
• English wrench set
• Allen wrench set (English and metric)
• Drill
• Hole saw
• Grinder
• Sharp utility knife
• Wire cutters
• Standard screwdriver
• Tape measure
• Permanent marker or another marking pen
• Smart Level
• Spray paint (if needed, color to match machine paint)
Required Personnel
A qualified welder is required to install brackets for mounting system components and hose clamps
for system cables. Be sure to arrange for a qualified welder to be on site for the planned installation.
Bench Test
A Bench Test procedure should be performed in advance of the actual machine installation.
Machine Inspection
Perform a machine inspection to confirm that the dozer is in an acceptable condition for machine
control applications.
● Look for any damage that would prevent the installation and operation of the components.
● Ask the operator to perform machine movements to confirm that the hydraulic system operates
within normal parameters.
Component Installation Locations
● Identify all sensors and bracket installation locations.
For complete information about performing a Bench Test, refer to the Bench Test
procedure described in the MC-X Dozer Systems Reference Installation and
Calibration Manual (P/N 1044736-01).
It is important to consider freedom of movement for various machine parts
when routing cables, as well as the potential for debris striking installed
components.
