13
NOMENCLATURE
Side surface
Cover is attached to the analog VGA connector. Don't use this connector.
DVI connector: Used to connect with the external devices (CV-5000 only). Ask the
serviceman to connect the instrument with the external devices.
AC adapter jack: Used to connect the power plug.
8
7
7
8
