NOMENCLATURE
NOMENCLATURE
Front surface
Liquid crystal display: Presents the chart.
Fixation target lamp: Used for the Maddox test and others.
Pilot lamp: Displays the power supply condition of the instrument.
Lower rear surface
Mounting hole (4 places): These screw holes are used to install the instrument on the wall-
mounting metal fixture or the Floorstand.
Function switch (3 pcs.): Used to set the instrument.
Power switch: Turn on this switch. The pilot lamp is lit green and the instrument can
receive the image signal.
CAUTION
To avoid electric shock, do not touch the external connection terminal
and the patient at the same time.
