15
PREPARATION BEFORE USE
1 Decide the position to install the wall-mounting
metal fixture on the wall. The standard for position-
ing is that the horizontal line stamped on the wall-
mounting metal fixture should be aligned with the
center height of the liquid crystal display. Fix the
metal fixture on the wall securely with the four
wooden screws, which are the accessories.
2 Fix the four wall-mounting screws on which the clearance rings are set into the screw holes on
the instrument's rear surface securely.
3 Hang the instrument on the wall-mounting metal fixture.
CAUTION
When installing the instrument on a wall, use the wall-mounting metal
fixture, which is one of the components, and install it on the strong wall
that can support its weight. (Do not install it on the plaster-board wall.)
The instrument may fall off to cause a trouble or injure someone.
CAUTION
Fix the wall-mounting metal fixture on the wall as taking care for its
direction. The instrument may fall off to cause a trouble or injure some-
one. If the instrument is installed slantwise, the reliability of the mea-
surement result may be lowered.
Clearance ring
Wall-mounting screw
To Next Page
