Patient No.
Instrument No.
VD (vertical distance)
Cylindrical power mark
Results of 5 refractory
power measurements of
right eye (recordable up to
10 measurements)
Typical value of right eye
Results of 5 refractory
power measurements of
left eye (recordable up
to 10 measurements)
Typical value of left eye
PD (pupil distance)
Results of 5 right eye cor-
neal curvature measure-
ments of right eye,
average value and astig-
matic power of cornea
(recordable up to 10 mea-
surements each for right /
left eye)
Typical measured value
of right eye corneal
curvature
Measured value of right
eye cornea (mm)
Measured value of left eye
Reliability mark
(displayed when reliability is low)
<R/K><KRT> mode
The kerato data display in the case of setting
the HV display as the R1R2 display.
STD 2 FORMAT, see “Setting communication format” on page 45.
MM1:Radius of curvature
of second principal
meridian
MM2:Radius of curvature
of first principal
meridian
A 1:Angle of second prin-
cipal meridian
