58
BASIC OPERATIONS
COLLIMATION AND MEASUREMENT
(ADJUSTING THE PATIENT'S EYE TO AUTO REFRACTOMETER)
Alignment operations are done with the control lever.
• The main body position can be fine-adjusted laterally by inclining the control level to each
direction.
• The main body position can be fine-adjusted vertically by turning the control level right (up)
and left (down).
Movement operations of the main body using the control lever.
Operating the control lever
(for lateral adjustment)
Operating the control lever
(for up/down adjustment)
