ASSEMBLY PROCEDURE
ASSEMBLY PROCEDURE
SECURING THE POWER UNIT
• The tabletop SO-TABLE06 and SO-TABLE07 is optional accessory.
1 Affix the power supply to the back of the tabletop with 4 screws.
SECURING THE TABLETOP SO-TABLE06 (OPTIONAL ACCESSORY)
FITTING TO AUTOMATIC INSTRUMENT TABLE AIT-16
1 Place the tabletop on the instrument table, and secure it with the 4 bolts attached to the instru-
ment table.
SECURING THE TABLETOP SO-TABLE07 (OPTIONAL ACCESSORY)
1 Peel off the tape which secures the plastic washer to the mounting bracket’s shaft.
CAUTION
To prevent falling during use and movement, secure each unit.
* The illustration depicts the SO-TABLE06.
