23
OPERATION PROCEDURE
OPERATING THE MICROSCOPE UNIT
Turn the magnification selector to set a magnification value against the magnification index mark.
NOTE
For the overall magnification in conjunction with magnification marks of the
magnification selector handle, see page 35.
Magnification selector
handle
Magnification index mark
