Topcon Synergy GM-50 series User Manual

7-7
7 DATA COLLECTION
7.2 Operational Procedure of DATA COLLECT
Operating procedure Operation Display
1 Press the {F3} (FS/SS) key from the data collect
menu 1/2.
The previous data is shown.
{F3}
2 Press the {F1} (INPUT) key and enter PT#.
Press the {F4} (ENT) key. *1)
{F1}
Enter PT#
{F4}
3 Enter PCODE, R.HT in the same way. *2),3)
4 Press the {F3} (MEAS) key.
5 Collimate the target point.
{F1}
Enter
PCODE
{F4}
{F1}
EnterR.HT
{F4}
{F3}
Collimate
6 Press one of the {F1} to {F3} key. *4)
Example: {F2} (SD) key.
Measuring starts.
The measuring data is memorized and the display
changes to the next point. *5)
PT# is automatically incremented.
{F2}
7 Enter the next point data and collimate the next
point.
Collimate
8 Press {F4} (ALL) key.
Measuring starts in the same measuring mode of
the previous point.
Data is recorded.
Continue the measuring in the same way.
To finish the mode, press {ESC} key.
{F4}
DATA COLLECT 1/2
F1:OCC.PT# INPUT
F2:BACKSIGHT
F3:FS/SS P
↓
PT# →
PCODE :
R.HT : 0.000 m
INPUT SRCH MEAS ALL
PT# =PT-01
PCODE :
R.HT : 0.000 m
[ALP][SPC][CLR][ENT]
PT# :PT-01
PCODE
→
R.HT : 0.000 m
INPUT SRCH MEAS ALL
PT# → PT-01
PCODE :TOPCON
R.HT : 1.200 m
INPUT SRCH MEAS ALL
VH *SD NEZ P1
↓
V : 90°10'20"
HR: 120°30'40"
SD*[n] < m
> Measuring...
< complete >
PT# → PT-02
PCODE :TOPCON
R.HT : 1.200 m
INPUT SRCH MEAS ALL
V : 90°10'20"
HR: 120°30'40"
SD*[n] < m
> Measuring...
< complete >
PT# → PT-03
PCODE :TOPCON
R.HT : 1.200 m
INPUT SRCH MEAS ALL
