Topcon Synergy GM-50 series User Manual

6-33
6 SPECIAL MODE (Menu Mode)
 Input CURVE data
Operating procedure Operation Display
1 To input CURVE data, press the {F2} key. *1)
{F2}
2 Input RADIUS.
3 Press the {ENT} key.
4 Input LENGTH.
5 Press the {ENT} key.
6 Select TURN (direction of turn): RIGHT or LEFT.
7 Press the {ENT} key.
Input
RADIUS
{ENT}
Input
LENGTH
{ENT}
Select
{F1}
(LEFT)
or
{F2}
(RIGHT)
{ENT}
*1) CURVE cannot be input as the first data.
F1:LINE
F2:CURVE
F3:SPIRAL
F4:POINT
CURVE 02
R = 0.000 m
L : 0.000 m
--- --- [CLR] [ENT]
CURVE 02
R : 100.000 m
L = 0.000 m
--- --- [CLR] [ENT]
CURVE 02
TURN > RIGHT
LEFT RIGHT --- ENTER
<SET!>
