Topcon System 150 User Manual

2-4
www.topconpa.com
System 150 Auto Steer Setup Guide
Figure 2-5. Edit Approach Aggressiveness
2
Use the 2. up arrow button to increase approach aggressiveness and
use the down arrow button to decrease approach aggressiveness
Select to conrm your selection or select to cancel. Either 3.
selection will return you to the Steering Tuning screen (gure 2-4)
3
Sensitivity
Sensitivity is an AES-25 electric steering specic tuning feature. The
higher the sensitivity, the more the steering wheel reacts to wheel
movement to keep the vehicle moving accurately along a guidance
path.
It is recommended that sensitivity be set at higher values when moving
at high speeds and at a lower value when moving at low speeds.
Figure 2-6. Steering Tuning screen
1
