Topfield TF 520 PVRt - Page 14

10 Setup
.
.
.
4
AUDIO L/R Stereo audio output socket for the televi-
sion set or the audio-video receiver (white/red)
.
.
.
5
TV Audio and video output socket for the tele-
vision set
.
.
.
6
VCR Audio and video input/output socket for
another device such as a video recorder
.
.
.
7
HDMI Audio and video output socket for the high
definition television set
.
.
.
8
USB USB port for firmware update and data trans-
fer
.
.
.
9
RS-232 Serial port for firmware update and data
transfer
.
.
.
10
S/PDIF Digital audio output socket for the audio-
video receiver
.
.
.
11
ON/OFF Power switch (You have to turn on this switch
first to use this digital receiver.)
Table 2.3: Connectors specifications
HDMI High definition video output
Left & right audio output
Digital audio output
VIDEO Composite video (CVBS) output
AUDIO Left & right audio output
TV CVBS/S-Video/RGB video output
Left & right audio output
VCR CVBS video output
Left & right audio output
CVBS/S-Video/RGB/YUV video input for bypass
Left & right audio input for bypass
S/PDIF Digital audio output
RS-232 115.2 kbps at maximum
USB 2.0 Device
