2.3 Wiring Instruction
2.3.1 Interface Broad
GND
+5V
Lmt_X+
LASER-2 LASER-1
GND
+5V
Lmt_Z/U/V+
Foot_SW
Door_SW
GND
+24
AXIS-X
TL-410C
Lmt_X-
Lmt_Y+
Lmt_Y-
Lmt_Z/U/V-
GND
+24V
WIND
OUT1
DIR-
PUL-
+5V
AXIS-Z/U/V AXIS-Y
DIR-
PUL-
+5V
DIR-
PUL-
+5V
PC U-DISK HANDSET
GND
WP2
LON-2
+5V
LPWM2
GND
WP1
LON-1
+5V
LPWM1
CN-2 CN-1
CN-3
POWER-IN
Fig. 2-6
2.3.2 Wiring Diagram
2.3.2.1 Motor Wiring
The following is X axis motor wiring, other axis are similar.
1. Step Motor Wiring
