1.5 Accessory List
The Laser Engraving Control System TL-410 contained the accessories as below:
Name
Qty
Introduction
Operation
Panel
1
For user
operation
Controller
1
The Motion
Control Card
GND +5V
Lmt_X+
LASER-2 LASER-1
GND
+5V
Lmt_Z/U/V+
Foot_SW Door_SW
GND
+24
AXIS-X
TL-410C
Lmt_X- Lmt_Y+ Lmt_Y-
Lmt_Z/U/V-
GND +24V WIND OUT1 DIR- PUL- +5V
AXIS-Z/U/V AXIS-Y
DIR- PUL- +5V DIR- PUL- +5V
PC U-DISK HANDSET
GND
WP2
LON-2
+5V
LPWM2
GND
WP1
LON-1
+5V
LPWM1
CN-2 CN-1
CN-3
POWER-IN
Connection
cable
3
1.Panel
Connection
cable for
connecting
controller and
panel.
2.USB
communication
cable for
