Topwisdom TL-410 - Input

泰智科技
Shenzhen Topwisdom Technology Co., Ltd
16
3
LON-2 Laser enable control
When the laser is CO2 laser, used to control laser On/Off
4
WP2 Laser status, the corresponding instruction is LED D4
When the laser is RF laser, used to the state input of laser
When the laser is CO2 laser, used to the state input of water conservation
(active low)
5
GND +5V power source grounding(output)
2.4.6 Input
The limit interface
 X, Y axis limit interface
Pin
Definition
1
+5V 5V power source positive (output)
2
Lmt_X+ X upper limit, axis movement to the max coordinate limit sensor
input
3
Lmt_X- X origin limit, axis movement to the minimum coordinate(0)limit
sensor input
4
Lmt_Y+ Y upper limit, axis movement to the max coordinate limit sensor
input
5
Lmt_Y- Y origin limit, axis movement to the minimum coordinate(0)limit
sensor input
6
GND 5V power source grounding (output)
 Z/U/V axis limit and input interface
Pin
Definition
1
+5V 5V power source positive (output)
2
Lmt_Z/U/V+ Z/U/V upper limit, axis movement to the max coordinate limit
