2.4.4 Output
The driver interface
 X axis interface
Pin
Definition
1
+5V 5V power source positive (output) PUL+, DIR+
2
PUL- Step pulse (output) PUL-
3
DIR- Direction signal (output) DIR-
 Y axis interface
Pin
Definition
1
+5V 5V power source positive (output) PUL+, DIR+
2
PUL- Step pulse (output) PUL-
3
DIR- Direction signal (output) DIR-
 Z/U/V axis interface
Pin
Definition
1
+5V 5V power source positive (output) PUL+, DIR+
2
PUL- Step pulse (output) PUL-
3
DIR- Direction signal (output) DIR-
4
GND External 5V power source grounding (output)
Note: The Z/U/V axis interface is multiplexing interface. It is able to change the function
of this port for Z, U, or V in the Equipment Parameter.
The general output interface
 The general IO output interface
Pin
Definition
1
EX5V External 5V power source positive (output)
2
OUT1 Work Completion / Feeding / Press / Work Status / Pen output
signal multiplexing interface.
