Thetraysolenoidshaveadjustmentscrewsthatallowyou
toadjusttrayinandtrayoutspeeds.Thesolenoidshave
beenpre-adjustedbeforeshipping.Aircushionpinvalves
ateitherendoftheaircylindercanbeadjustedtocontrol
dampingatextremeendsofcylindertravel.Thesearealso
pre-adjusted.Toolchangemeshouldnotbeadjustedto
lessthan8seconds.Conversely,movingtooslowlywill
triggeranerrorcondion.
Tray Solenoids
