Tormach ATC - System Requirements

theATCtoprovideandensurepointofoperaon
safeguardingperOSHAstandards.
Electrical Safety
TheTormachToolingSystemATCoperateson
70VDC,fusedat8amps.Itispoweredfrom
theDCBusBoard(PN32005)insidethecontrol
cabinetofthemill.Neveroperatethe
machinetoolwiththecabinetdooropen.Nevermakeor
checktheseconneconswiththemillpoweredon.
PowertotheATCandotherdevicesinsidethecontrol
cabinetmayretaindangerousvoltagesaerexternal
powerhasbeenremoved.Donotmodifythese
conneconsinanyway.Ifunsureabouttheconnecons,
callTormachoraqualiedrepairtechnician.
1.3 System Requirements
TousetheTormachToolingSystemATC,yourmachine
mustmeetthefollowingrequirements:
• Youmustprovideacompressedairsourcecapableof
deliveringclean,dryairat95PSIand2CFM.
• TheTormachPowerDrawBar(PN31706)mustbe
installed
• ForPCNC1100machinesserialnumbers1325and
lower,youmusthavepreviouslyinstalledtheSpindle
DriveUpgradekit(PN31090)
• ForPCNC1100machinesserialnumbers999and
lower,youmusthavepreviouslyinstalledtheSeries3
upgradekit(PN32010)
Required Tools
• MetricAllenwrenchset
• Screwdrivers
• Boxwrenchesandlargecrescentwrench
• Hotgluegun
• 12”longwoodendowelorroundstock
2
3
UM10081_TTS_ATC_PCNC1100_1013A UM10081_TTS_ATC_PCNC1100_1013A
