Tormach ATC - ATC Electrical

10.6 ATC Electrical
ATC J1 – Power (Molex Mini Jr 4)
ATCJ1 P1 +70Vin
ATCJ1 P2 +70Vin
ATCJ1 P3 Gnd
ATCJ1 P4 Gnd
ATC J2 - Solenoids/Estop (Molex Mini Jr 12)
ATCJ2 P1 Solenoid5+12V
ATCJ2 P2 Solenoid4+12V
ATCJ2 P3 Solenoid3+12V
ATCJ2 P4 AirBlastSolenoid+12V
ATCJ2 P5 ToolTraySolenoid+12V
ATCJ2 P6 Estop(notused)
ATCJ2 P7 Solenoid5-Gnd
ATCJ2 P8 Solenoid4-Gnd
ATCJ2 P9 Solenoid3-Gnd
ATCJ2 P10 AirBlastSolenoid-Gnd
ATCJ2 P11 ToolTraySolenoid-Gnd
ATCJ2 P12 Estop(notused)
ATC J3 - Switches and Sensors (Molex Micro 12)
ATCJ3 P1 unused
ATCJ3 P2 unused
ATCJ3 P3 CylinderInSwitch/+5V
ATCJ3 P4 ToolTrayHomingSwitch/+5V
ATCJ3 P5 CylinderOutSwitch/+5V
ATCJ3 P6 ExtraSwitch/+5V
ATCJ3 P7 unused
ATCJ3 P8 unused
ATCJ3 P9 CylinderInSwitch/Gnd
ATCJ3 P10 ToolTrayHomingSwitch/Gnd
ATCJ3 P11 CylinderOutSwitch/Gnd
ATCJ3 P12 ExtraSwitch/Gnd
