Tormach ATC - Before You Begin; Mounting the ATC

2.2 Before You Begin
TheTormachToolingSystemATCisdesignedformachines
withthepowerdrawbar(PN31706)installed.PCNC1100
millingmachineswithserialnumbers1325andlower
willneedtohavethespindledriveupgrade(PN31090)
installedbeforeinstallingtheATC.PCNC1100machines
withserialnumbers999andlowerwillalsohavetohave
theSeries3upgradekit(PN32010)installedbefore
installingtheATC.
Allmachineswillneedtohavethepowerdrawbarinstalled
beforeinstallingtheATC.Seethepowerdrawbarmanual
(includedwiththepowerdrawbarpackageandontheATC
sowareCD)forpowerdrawbarinstallaoninstrucons.
PCNC1100machinesserialnumbers1999andlowerwill
needtoreplacetheoldDCBusBoard(PN30661)withthe
newbusboard(PN32005).
2.3 Mounting the ATC
MounngandaligningtheATCtothemillisajobthatis
bestdonewithtwopeople.TheATCcarouselassembly,
whichweighsapproximately50pounds,iscumbersometo
liandposionaccuratelyespeciallywhenworkingover
themill’schiptray.Installaongoessmoothlywhenone
personholdstheATCinposionwhileanassistantghtens
thefastenersthatconnectittothesquaretubemount.
Initial Hardware Installation
WARNING! SHUT THE COMPUTER
DOWN, THEN POWER DOWN THE MILL
USING THE ROTARY SHUTOFF SWITCH
ON THE RIGHT HAND SIDE OF THE
CONTROL CABINET.
Youmayndinstallaoneasiestifyourstpullthemill
awayfromthewall.
Ifed,removethecoolanthoseandmountfromthe
spindle head.
Ifed,removethelehandmachinearmfromthemill
column.
4
5
UM10081_TTS_ATC_PCNC1100_1013A UM10081_TTS_ATC_PCNC1100_1013A
