10.1 ATC Carousel
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 32149 ToolTrayDoor 1
2 32133 TrayArmPin-Front 1
3 32150 TrayDoorThrustBearing-Lower 1
4 32148 DoorThrustBearing-Upper 1
5 32195 M6x5FlatHeadScrew 1
6 32131 TrayDoorArm 1
7 32132 TrayArmPin-Rear 1
8 32192 M3x12SHCS 2
9 32136 12mmC-Clip 3
10 32135 TrayLeverWasher-Rear 1
11 32134 LeverWasher-Front 1
12 32151 Spring Washer 1
13 32153 CowlingStando 4
14 32160 ToolTraySensorHousing 1
15 32162 TraySensorHousing-Top 1
16 32166 6PinMolexHeader 1
17 32164 TraySensorAssembly 1
18 21205 M6x30SHCS 4
19 32155 ToolTrayCowling 1
20 32169 10-32x1/4PushConnector 5
21 32141 BlastUnionBlock 1
22 32180 1/4RollPin 1
23 32152 ToolTrayHub 1
24 32159 ToolClaw 10
25 32156 ToolTrayPlate 1
26 32158 ToolClawSpring 10
27 32173 M6X16NylonHexBolt 20
28 32174 M14FlangeNut 1
29 32176 M14x30Stud 1
30 32157 TraySenerWasher 1
31 32179 M5x12SetScrew 2
32 32177 M8x10HubRetenonBolt 1
33 32178 Magnet 1
34 32236 LidScrew 4
35 32243 Blastnozzle 2
36 32232 PUR1/4AirLine 2
34
35
