10.3 TTS ATC Actuator
ITEM NO. PART NUMBER DESCRIPTION
1 32187 M10FlangeNut
2 32186 M10x25SHCS
3 32122 InterfaceMount
4 32123 Rail
5 32124 LinearBearing
6 32183 M8x16LowHeadSHCS
7 32125 BearingSpacerBlock
8 32126 FrontCylinderBracket
9 32188 M6x25SHCS
10 32190 M6FlangeNut
11 32145 MotorChassisCover
12 32130 Cylinder3/4x16JamNut
13 32142 1/8NPTx1/4PushConnector
14 32137 Band Clamp
15 32172 7/16JamNut
16 32127 CylinderRodBracket
17 32143 MotorChassis
18 32182 M8x35SHCS
19 32189 M6x16SHCS
20 32147 Gear Head
21 32146 NEMA34Motor
22 32191 M6x24SHCS
23 32200 Molex20PinHeade
24 32199 20PinMolexPlug
25 32249 ConneconBoxLid
26 32250 M3x5PanHead
27 42249 CableChafeGuard
28 32129 RailCoverPlate
29 32140 FlexCableRetainer1/2NPT
30 32139 FlexCableRetainer-1/4NPT
31 32193 M3x5SHCS
32 32203 4PinMolexHeader
33 32138 CylinderSensorModule
34 32128 AirCylinder
35 32201 M4x25PHScrew
38
39
