Tormach ATC - Page 46

ATC J4 - Tormach Stepper Ribbon (IDC 10)
ATCJ4 P1 unused
ATCJ4 P2 unused
ATCJ4 P3 +5Vcommon
ATCJ4 P4 Step
ATCJ4 P5 Direcon
ATCJ4 P6 unused
ATCJ4 P7 unused
ATCJ4 P8 unused
ATCJ4 P9 unused
ATCJ4 P10 unused
ATC J5 - ATC (RJ-11)
ATCJ5 P1 DrawBarBoardInputSignal(VFD,SolenoidStatusviaPWM)
ATCJ5 P2 DrawBarOutput-UP
ATCJ5 P3 DrawBarOutput-DN
ATCJ5 P4 DrawBar/Gnd
Stepper Driver Dip
Sw 1 On
Sw 2 O
Sw 3 On
Sw4 On
Sw5 On
Sw 6 O
Sw7 On
Sw 8 On
44
PB
UM10081_TTS_ATC_PCNC1100_1013A UM10081_TTS_ATC_PCNC1100_1013A
