Instructions for Use T-1929 e 19
8 Appendix
8.1 Hint and Fault Table
System behaviour No. Cause Remedy/ rectification
The door reverses when
opening.
H31 Electronic obstacle recognition on
opening by a person, wind pressure,
ventilation or dirt in the floor guide.
Remove the obstruction.
Clean the floor guide.
Door reverses when
closing.
H32 Electronic obstacle recognition on
closing by a person, wind pressure,
ventilation or dirt in the floor guide.
Remove the obstruction.
Clean the floor guide.
The door stops repeat-
edly when opening.
H33 Electronic obstacle recognition on
opening in the same position by
stationary obstacle.
Remove the obstruction.
Clean the floor guide.
The door stops repeat-
edly when closing.
H34 Electronic obstacle recognition on
closing in the same position by sta-
tionary obstacle.
Remove the obstruction.
Clean the floor guide.
Door remains open. H41 Step function active. Automatic reset after an impulse.
Door remains open. H44 Manual reset button > 1 min. ac-
tive.
Have the sensor repaired by a
qualified person.
Reset key switch.
Door stays still. H45 Door leaf deflected. Engage the door leaf.
Otherwise have the system re-
paired by a qualified person.
Search run notified. H61
H62
Search run of the door after a reset
or after power recovery.
Allow the search run to travel its full
course.
Door operates at a re-
duced speed.
H71 Battery operation Wait for power recovery,
switch on mains supply.
Door remains open or in
normal operation.
H72 Battery charge < 15 % Wait until the battery is suciently
charged.
Door remains closed. Operating mode such as OFF, EXIT
or P.
E.g. select operating mode
AUTOMATIC 1.
Door remains open. Operating mode such as OPEN or P. E.g. select operating mode
AUTOMATIC 1.
Door stays still. E0 … Safety shutdown of control. Perform software reset.
Otherwise have the system re-
paired by a qualified person.
The door does not lock
in OFF.
E11 Lock is jammed or defective. Push the door leaves for a few se-
conds against the closed position in
operating mode OFF when the door
is closed. Have the system repaired
by an expert.
The door does not open
after changing from
OFF to AUTOMATIC.
The lock makes switch-
ing noises from time to
time.
E11 Lock is jammed or defective. Push the door leaves for a few se-
conds against the closed position in
operating mode AUTOMATIC 1.
Have the system repaired by an
expert.
