4 Instructions for Use T-1929 e
1.4 Explanation of the Symbols
Warning (signal word)
Source of hazard (designates a possibly hazardous situation)
Possible consequences of non-observance
• Measures for averting danger.
Text which is highlighted in grey MUST be observed to ensure that the system operates perfectly.
Failure to observe these chapters can cause damage to equipment.
Functions marked with this symbol are the factory setting. However, they can be repro-
grammed by a qualified person.
Optional components which are not present in all systems.
1.5 Technical Data
Drive type Electro-mechanical sliding door drive with an DC motor
Control system Control unit MCU42
Mains connection
1 × 230 V | 10 – 16 A
1 × 115 V | 15 – 20 A
Power consumption max. 230 W
Sensor supply
24 V DC (+0.5 –1.5 V) 15 A, in battery operation min. 16.5 V
Protective class, drive IP20
Fuse 8 AT
Ambient temperature –20 °C to +50 °C, humidity non-condensing
Emission sound pressure
level
Typically 55 dB (A) at 50 cm/s, depending on door and substructure
Electromagnetic
compatibility (EMV)
IEC 61000-6-2, IEC 61000-6-3
Service life
Tested to 2 000 000 cycles
