QUICK REFERENCE − DECO 13A
en 300417 − 04/08 16
1.10 GLOBAL PROGRAM VARIABLES
#2011 X1 Position <PR> at end−of−cutoff, accounting for
LX of cutoff tool
#2012 Z1 Position <PR> for cutoff
(part length)
#2013 Z4 Position <MC> before part in cutoff position and
accounting for #3012
#2014 Z4 Position <MC> for part pickoff acc. to #3009
#2015 Z4 Position <MC> for retract after part pickoff
#2016 G56 Z4 Zero Offset to enter before 1st backwork
#2017 For long parts, bar position for clamping
#2018 Add−on zero offset Z1 for bar feed
#2019 G56 Z3 Zero Offset to enter before 1st frontwork (T31 − T34)
#2020 Cutoff Tool No. to be used by TB−Wizards
#2021 Save Z1 Position <MC> after feed over G912. This data will be
used in Macro G915.
#2022 For long parts, value of the cutting tool geometry on cutting
side.
#2025 For long parts, approach position clamping <PR> on G100, X1
and X2 axes
#2026 For long parts, <PR> clamping pos.,X1 and X2 axes
#2029 Pos. <PR> of Z4 before extraction taking into account T50
