QUICK REFERENCE − DECO 13A
en 300417 − 04/08 9
1.6 G−FUNCTIONS (PREPARATORY)
Code Function Grp. M/S
G01 Linear interpolation 10 S
G02 Circular interpolation, cw 10 S
G03 Circular interpolation, ccw 10 S
G04 Dwell [s] at 100% override 1 S
G13 Loop Start 1 S
G26 Circular chamfer link
L = radius
2 S
G27 Linear chamfer link
L = width
2 S
G28 Referencing 10 S
G33 Threading, constant lead 9 S
G34 Threading, increasing lead 9 S
G35 Threading, decreasing lead 9 S
G40 Cutter compensation cancel 2 M
G41 Cutter compensation, left 2 M
G42 Cutter compensation, right 2 M
G52 Cancel all zero offsets (datum shifts).
Coordinate system begins at Machine Zero and
is again valid for the axis / axes concerned.
1 M
G53 Cancel all additional zero offsets (datum shifts),
programmed via G54 and G55.
1 M
G54 Additional zero offset (datum shift) against cur-
rent coordinate system. This offset is additional
for the axes concerned.
1 M
