QUICK REFERENCE − DECO 13A
en 300417 − 04/08 10
M/SGrp.FunctionCode
G55 Additional zero offset (datum shift) against ini-
tial coordinate system (Part Zero).
Cancels G54.
1 M
G56 Zero offset (datum shift) against Machine Zero.
Initial G56 settings, processed at each program
start, are those entered in Part Manager
1 M
G58 Save all zero offsets (datum shifts) and reset
them for the axes concerned to cut with respect
to Machine Zero
1 M
G59 Restore all zero offsets (datum shifts) saved via
last G58 for the axes concerned
1 M
G68* Cancel G69 2 M
G69 Calculate 360 modulo for rotary axis 2 M
G70 Inch data input (not for tools) 2 M
G71* Metric data input 2 M
G81 Linear extension for cutter compensation 2 M
G82* Circular extension for cutter compensation 2 M
G83 Permute axes for main plane of interpolation 2 M
G84 Permute axes for main plane of interpolation 2 M
G85* Reestablish main plane as specified in Opera-
tion Line. Cancels G83 or G84
2 M
