QUICK REFERENCE − DECO 13A
en 300417 − 04/08 17
1.11 M−FUNCTIONS
Code Function Note Res
p.
M/S
M1 Program stop, optional Enter in a
separate block
DO1921
no M
M2 Program stop unconditional with reset (DO1922) no M
M8 Coolant ON (DO1904) no M
M9 Coolant OFF (DO1905) no M
M10 Close spindle collet (clamp) (DO1901) yes M
M11 Open spindle collet (unclamp) (DO1900) yes M
M20 End−of−part signal;
It increments Part Counter
(DO1923) no S
M32 Tool break check on Sens.1 (DO1942) no S
M33 Part pres. check on Sens.1 (DO1943) no S
M34 Tool break check on Sens.2 (DO1944) no S
M35 Part pres. check on Sens.2 (DO1945) no S
M36 Tool break check on Sens.3 (DO1946) no S
M37 Part pres. check on Sens.3 (DO1947) no S
M45 HP pump On (DO1950) yes S
M46 HP pump Off (DO1951) yes S
M60 Load a new bar (DO1927) no S
M82 Barfeeder thrust ON (DO1931) no S
M83 Barfeeder thrust OFF (DO1932) no S
M84 Feed pickoff−spindle ejector (DO1954) yes S
M85 Retract pickoff−spindle ejector (DO1955) yes S
M101 Program stop at end−of−table (DO1920) no S
