QUICK REFERENCE − DECO 13A
en 300417 − 04/08 27
Axial Backwork Gang Tools:
1st geometry 2nd geometry Support
T41 T45 41
T42 T46 42
T43 T47 43
Radial Backwork Gang Tools
1st geometry 2nd geometry Support
T51 T54 51
T52 T55 52
T53 T56 53
T40: Pickoff spindle geometrics for part pickoff
T50: Gripper / cage geometrics for part ejection
