tornos MULTIDECO Series - 3 Location;Installation; Floor Plan

INSTALLATION – MULTIDECO 26/6 – MULTIDECO 32/6i
300381 en – 06/02 Chap. 3.1 /1
3. LOCATION/INSTALLATION
3.1 FLOOR PLAN
⇒ Note:
The dimensions relate to the standard configuration with optional (addi-
tional) tank and cooler. Be sure to take into account for your particular
floor plan the dimensions of other options added to the machine, such
as barfeeder, mist & smoke control unit, etc.
>>>
