INSTALLATION – MULTIDECO 26/6 – MULTIDECO 32/6i
300381 en – 06/02 Chap. 3.5 /19
3.5 ELECTRIC INSTALLATION MULTIDECO 32/6i
XS18
TC1 transformer,
see Fig. 314
XT0 input
terminal box
QS0 main
switch
RS232 Socket
Fig. 312Fig. 311
