3.4.2 Electric Connection to 200V – 240VAC Mains
Mains
200V to 240VAC
50Hz/60Hz
Connect general electrical installation supply to machine
Section acc. to ASE 70mm
2
or acc. to local regulations.
Mains
Input terminal box XT0
See Fig. 310
L1
L2
L3
L1
L2
L3
Switch off general electrical installation supply
Check connections on TC1 transformer and
TM2 autotransformer, see Figs. 308 and 309
Mains TM2 input TM2 output TC1 input
200V 50Hz
200V 60Hz
220V–240V 50Hz
220V–240V 60Hz
200V
200V
230V
230V
400V
460V
400V
460V
200V
200V
230V
230V
