tornos MULTIDECO Series - Electric Connection to 380 V - 480 VAC Mains

INSTALLATION – MULTIDECO 26/6 – MULTIDECO 32/6i
300381 en – 06/02 Chap. 3.4.3 /15
3.4.3 Electric Connection to 380V – 480VAC Mains
Mains
380V to 420VAC /
50Hz
440V to 480VAC /
60Hz
Connect general electrical installation supply to machine
Section acc. to ASE 35mm
2
or to local regulations.
Mains
Input terminal box XT0
See Fig. 310
L1
L2
L3
L1
L2
L3
Switch off general electrical installation supply
1
