INSTALLATION – MULTIDECO 26/6 – MULTIDECO 32/6i
300381 en – 06/02 Chap. 1.6 /5
1.6 PRESENTATION MULTIDECO 32/6i
8
7
6
5
4123 109
1. See–thru door for machining range
Ident. no. 217439
2. See–thru door for chuck and feed range
Ident. no. 217441
3. See–thru door for spindle housing
Ident. no. 217440
5. See–thru door for manual chucking range
Ident. no. 217441
6. NC Keyboard
7. Switch cabinet
8. Control panel
9. NC screen
10. See–thru door with opening on part output side
Ident. no. 217442
11. See–thru door for access to gear housing
Ident. no. 217441
Item nos. 1, 2, 3, 5, 10, 11: See–thru door alone with glued guiding “U” profile.
