tornos MULTIDECO Series - Electric Connection to 500 VAC Mains

INSTALLATION – MULTIDECO 26/6 – MULTIDECO 32/6i
300381 en – 06/02 Chap. 3.4.4 /17
3.4.4 Electric connection to 500VAC mains
1
Mains
500VAC 50Hz / 60Hz
Connect general electrical installation supply to machine
Section acc. to ASE 35mm
2
or acc. to local regulations.
Mains
Input Terminal Box XT0
See Fig. 310
L1
L2
L3
L1
L2
L3
Switch off general electrical installation supply
Check connections on TC1 transformer and on
TM2 autotransformer, see Figs. 308 and 309
Mains TM2 input TM2 output TC1 input
500V 50Hz
500V 60Hz
500V
500V
400V
460V
500V
500V
