INSTALLATION – MULTIDECO 26/6 – MULTIDECO 32/6i
300381 en – 06/02 Chap. 3.6.1 /24
3.6 PNEUMATICS INSTALLATION
3.6.1 Required air quality
∆ Caution!
– The machine must be supplied with dry, oil–free air.
– If the air in the connected network contains oil or condensate, it is
necessary to install an air drier at the inlet to the circuit in order to
prevent incorrect functioning or machine breakdown.
Components
Operating pressure:
Consumption:
Description Characteristics
6 bar
6.3m
3
/h
Connection: Quick release
couplings
1/4”
Quality: in accordance with
Standard
ISO 8573 – 1
Quality class : workshop standard 4
Max. particle size: max.
15 µm
Mass concentration: mass 8 mg/m
3
Dew point under pressure: max. + 3 degrees
Oil concentration: max. 5 mg/m
3
See: STANDARD PNEUMATICS
⇒ Note :
For more details, consult your operating instructions entitled :
OPERATION & MAINTENANCE.
>>>
