INSTALLATION – MULTIDECO 26/6 – MULTIDECO 32/6i
300381 en – 06/02 Chap. 3.2.3 /8
305
4. Place the level perpendicularly to machine axis (Fig. 305) and check if
transverse axis of the base is horizontal. If necessary, adjust the setting
by means of levelling element nos. 1 and 4 by repeating the directional
checks under points 2 and 3.
3.2.3 Removing transport locks
Action Notes
Remove the wooden wedges and
ropes that hold various items in
place.
Oil tank, chip pan, manipulator,
hatches.
Remove mechanical locking
devices
Locking device
Put away the locking pieces for
possible future use.
∆ Caution!
Unlocking must not be performed until the machine has been set in
position.
