INSTALLATION – MULTIDECO 26/6 – MULTIDECO 32/6i
300381 en – 06/02 Chap. 3.4 /10
3.4 ELECTRIC INSTALLATION MULTIDECO 26/6
XS2 socket for
coolant motor
Fig. 307
XS38 socket for
chip conveyor
XS18
Fig. 306
TC1 transformer
see Figs. 308
and 309
XT0 input
terminal box
QS0 main
switch
Additional
tank
XS78
XS 94
Barfeeder
