INSTALLATION – MULTIDECO 26/6 – MULTIDECO 32/6i
300381 en – 06/02 Chap. 3.4.3 /16
Switch on main machine switch QS0, see Fig. 306
Check XS18 service socket
voltage see Fig. 306
220V–240V
or XS17 US–
socket
100V–110V
The machine is correctly installed
– Turn off main switch QS0
– Adjust voltage at TC1 transformer
input, see Fig. 308
1
no
yes
