InstallingandRemovingthe
CuttingUnits
InstallingtheCuttingUnits
1.Liftuponthefootrestandswingitopen,allowing
accesstothecentercuttingunitposition(Figure31).
CAUTION
Thefootrestcanpinchngersifitfallsinto
theclosedposition.
Keepyourngersclearoftheareawherethe
footrestseatswhileitisopen.
g014602
1
2
Figure31
1.Footrest—closed2.Footrest—open
2.Positionthecuttingunitunderthecentersuspension
arm.
3.Withthelatchesonthesuspension-armbarpointing
up(i.e.,open)(
Figure32),pushthesuspensionarm
downsothatthebartsoverthebaracrossthetop
ofthecuttingunit(Figure33).
g014609
1
2
3
Figure32
1.Latch—closedposition3.Latch—openposition
2.Suspension-armbar
g01461 1
1
2
Figure33
1.Suspension-armbar2.Cutting-unitbar
4.Closethelatchesdownandaroundthecutting-unit
barandlocktheminplace(Figure32).
Note:A“click”canbeheardandfeltwhenthe
latchesareproperlylockedinplace.
5.Coatthesplineshaftofthecuttingunitmotorwith
cleangrease(
Figure34).
6.Insertthemotorintotheleftsideofthecuttingunit
(asviewedfromtheoperator'sposition)andpull
themotorretainingbaronthecuttingunittoward
themotoruntilyouhearanaudible“click”from
bothsidesofthemotor(
Figure34).
30
