BatteryWarningLight
Thelight(Figure17)glowsifthebatterychargeislow .
EngineOilPressureLight
Thelight(Figure17)glowsiftheengineoilpressure
dropsbelowasafelevel.
WaterTemperatureLight
Thelight(Figure17)glowsandtheengineautomatically
shutsdownwhentheenginecoolanttemperaturegets
toohigh.Iftheengineshutsdown,youcanstartthe
engineanddrivethemachinefor10secondsbeforeit
willshutdownagain,allowingyoutomovethemachine
toalocationwhereyoucanallowittocooldown.
ServiceIndicatorLight
Theserviceindicatorlight(Figure17)illuminates
whenthemachinesensorsdetectanissuewithoneof
thesystemsofthemachine.Ifthislightilluminates,
stopwhatyouaredoinganddrivetoasafelocation
whereyouoraservicetechniciancandiagnose
theproblem.Formoreinformationondiagnosing
systemissuesusingtheserviceindicatorlight,referto
DiagnosingtheServiceIndicatorLight(page46).
GlowPlugIndicatorLight
Whentheglowplugindicatorlight(Figure17)islit,it
indicatestheglowplugsareon.
Note:Theglowplugindicatorlightmayilluminatefor
ashorttimeaftertheenginehasstarted;thisisnormal.
HourMeter
Thehourmeter(Figure18)indicatesthetotalhoursthe
machinehasoperated.Itstartstofunctionwheneverthe
keyswitchisrotatedtoOn.
g014600
1
Figure18
1.Hourmeter
ParkingBrakeLever
Pulluponthebrakelever(Figure15)tosettheparking
brake.Disengageitbypushingitforwardanddown.
Locktheparkingbrakeanytimeyouleavethemachine.
g01461 0
Figure19
BacklapLever
Thebacklapleverislocatedundertheplasticcoverto
theleftoftheseat.Usethebacklaplever(Figure20)in
conjunctionwiththeraise/lowermowcontrolleverand
thereelspeedcontrolforbacklappingthereels.
21
